439
Keysight Handheld Analyzers
N99xxA User’s Guide
18 Reflection Mode (SA Models) - Option 320
This feature may require an option. Please view the FieldFox Configuration
Guide at: http://literature.cdn.keysight.com/litweb/pdf/5990-9836EN.pdf
Reflection Mode measurements are very similar to CAT mode reflection
measurements. They provide 1-port scalar reflection measurements in selected
FieldFox SA-Only models. The FieldFox source is routed internally to Port 1
and used to stimulate a Device Under Test (DUT). The energy that is reflected
off the DUT is measured and displayed on the screen.
Option 320 requires Option 220 Tracking Generator. N9938A models
require Option 100 3.5 mm connectors and Option 220.
— Option 100 3.5 mm connectors must be installed by the factory. Option
100 is only available on N9938A at the time of purchase. It is not
available as a trial/upgrade.
— Option 220 Tracking Generator can be ordered via software license on
www.keysight.com.
Option 320 is not available on N991xA, N992xA, or N995xA models.
