Keysight N9927-90001 User’s Guide 331
5G Rapid Prototype Phased Array Antenna – Option 360
Using the Phased Array Antenna (Option 360)
Using the Phased Array Antenna (Option 360)
Option 360 enables you to do the following:
Measure and display phased array antenna elevation and azimuth
Four Display Types:
—Bore-Site
—Heat Map
— Polar Antenna
— Park Antenna
— Polar with Image Overlay
Color Coded Display Types:
— Specify high and low power with
color bars
Azimuth and Elevation:
— 8 x 8 phased array antenna — Covers beam sweep –60 to +60
degrees azimuth, 90-degree
elevation with 1 degree per step
— Individually factory characterized
elements, magnitude and phase
Data Logging. Record GPS stamped data measurements
— Define measurement interval by time
or distance
— Show results in TableChart
— Display files (KML) on Google Maps
or Google Earth
