352 Keysight N9927-90001 User’s Guide
5G Rapid Prototype Phased Array Antenna – Option 360
How to Set Up Phased Array Antenna Settings
How to Define a Set Up a Scan and Use Option 360
You can define measurements by selecting which type of data to display.
Data definitions consist of the following:
— Select the measurement type
— Define the antenna setting, using the antenna settings table
— Define other optional marker, sweep, averaging, bandwidth settings
Example: Refer to:
— “Step 1. Connect Your Equipment” on page 352
— “Step 2. Set FieldFox to Use Static IP with Your Ball Antenna” on page 352
— “Step 3. Define the measurement” on page 353
Then:
— “Step 4: Select Polar Settings” on page 355
— “Step 5. Modify Scale and Attenuator Settings” on page 355
— “Step 6: Enable Recording and Record Data Logging Results” on page 356
— “” on page 358
— “Step 7: Import and Play back KML Files into 3rd Party Software (Example:
Google Earth with Animation Tool)” on page 358
Step 1. Connect Your Equipment
Connect your equipment similar to Figure 1 on page 333.
Step 2. Set FieldFox to Use Static IP with Your Ball Antenna
— The Ball antenna’s default static IP address is: 192.168.1.10
— Set FieldFox to use static IP address:
Press System
IMPORTANT! The LAN address for first 3 fields must match the Static IP
address of FieldFox. For example, the Ball Antenna’s factory IP address is
192.168.0.10, set FieldFox Static IP address to 192.168.0.xx. “xx” must be
different number than shown in the last field of the for Ball Antenna. Refer
to Figure 14 on page 350.
IMPORTANT! If you forget you N9910X-028 Ball Antenna’s static IP
address, refer to this link and the Support tab for assistance:
www.keysight.com/find/fieldfox and then to the Phase Array Antenna
Support Document.
