Keysight N9927-90001 User’s Guide 353
5G Rapid Prototype Phased Array Antenna – Option 360
How to Set Up Phased Array Antenna Settings
—Then System Configuration > More > LAN
1. In the Setting screen, use the arrows, the rotary knob, or
numeric keypad to highlight Obtain IP.
2. Press Obtain IP Static
3. Press Clear, then set the Static IP Address to: 192.168.1.2
and
4. Press Done
5. Press Clear, then set the Static Subnet Mask to:
255.255.255.0
and
6. Press Done
7. Press Clear, then set the Static Gateway to: 192.168.1.254
and
8. Press Done
9. Using the arrows, the rotary knob, or numeric keypad to
select Apply Settings.
10. Press Edit
, then select Now.
11.Press Done Edit
> Done
Step 3. Define the measurement
1. Press Preset then Mode Preset (Factory)
2. Selecting Phased Array Antenna mode: Press Mode > Phased Array
Antenna. Depending on the number of options loaded on your FieldFox, it
may be necessary to press More
.
3. Optimizing the FieldFox to scan for signals:
a. Run the Antenna Wizard: Measure > Antenna Wizard
and follow the
prompts.
b. Set the Measure
type (i.e., Bore-Sight, Heat Map, Polar ANT, or Park
ANT).
See also “How to Set Up Phased Array Antenna Settings” on
page 341.
c. Set the Meas Setup
> Antenna Settings table:
— Ball Antenna: LAN address
— Settings: Res BW, Video BW, and Beam Width
