480 Keysight N9927-90001 User’s Guide
Pulse Measurements Mode – Option 330
Pulse Measurement Settings
Amplitude Markers
Amplitude markers are horizontal dotted lines that you can move to any
amplitude level on the screen. The two amplitude markers can be set
independently or used as a pair of delta markers.
Amplitude markers can be used as a visual comparison aid with the pulse
measurement traces.
How to make Amplitude Marker settings
—Press Marker
—Then More
—Then Ampl Markers
— Then choose from the following:
— OFF
Amplitude markers are NOT displayed.
— ON
Amplitude markers ARE displayed at their previous positions.
—Then Ampl Mkr 1 or 2
— Enter a value in dBm for the marker using the numeric keypad, the
arrows, or the rotary knob.
—Press Delta Ampl Mkr
— Then choose from the following:
— ON
AmplMkr 2 value is relative to AmplMkr 1. When AmplMkr 1 is
moved, AmplMkr 2 also moves to maintain the AmplMkr 2 value
between them.
— OFF
The two amplitude markers move independent of one another.
Marker Search
Use Marker Search to find and move markers to locations on the Tr 1 trace.
How to Search with Markers
— Activate the marker to be used for the search
—Then press Mkr ->/Tools
.
—Then Marker Search
—Then Zone Search
— Then choose from the following:
— ON
Available ONLY when the zoom window is enabled, the search is
limited to the zone defined by the zoom window.
— OFF
The search is performed over the entire Tr 1 trace.
