Keysight N9927-90001 User’s Guide 361
5G Rapid Prototype Phased Array Antenna – Option 360
How to Record/Playback (Option 360)
—Then Record
is displayed in the left of screen graticules.
During recording, choose from the following:
— Pause Resume
Temporarily halts recording until pressed again. The
incoming trace continues to sweep. Press again to continue recording.
— Stop
Immediately stops recording. Then choose from the following:
—Then Save Recall Rec-Playback
To save a log file, recall logs, or
change your file settings. Learn more, refer to “To change Recording
Configuration settings:” on page 361.
——Press Save Log File
to save the current Table data (i.e., default
save device is Internal).
—Then Record Settings
To change your measurement interval
settings. Learn more, refer to “To change Recording Configuration
settings:” on page 361.
To change Recording Configuration settings:
—Press Measure 1
—Then Data Logging then choose:
—Then Record Settings
—Optional: Then Meas Interval
> ON
——Then Interval Type
> choose Time or Distance.
——Then, if applicable Time Interval
enter time interval in seconds.
Or
——Then, if applicable Distance Interval
enter distance interval in
miters.
—Then Save Recall Rec-Playback
—Then Device
(Internal (default), SD Card, or USB)
—Then File Type
(CSV, DREC, or KML (default))
Learn more, refer to the Chapter 31, “File Management”.
How to Playback
—Press Measure 1
— If the session is already open, skip the following step. Otherwise:
To Next Page
