388 Keysight N9927-90001 User’s Guide
On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on
N991xB), GPS (Option 307) and GPS Receiver (Option 307))
Importing a .zip File to the FieldFox
Importing a .zip File to the FieldFox
On the FieldFox:
Press System 7
> Utilities > Mapping > Map Explorer (Get Maps)
1. Press Import Maps
2. Press Do Import (.zip)
3. In the "Select .zip file to import" window that opens, if there is
more than one .zip file listed, select the .zip file you want to load by using
the arrows, or the rotary knob and then press Recall File
.
Refer to Figure 15-11 on page 389 and Figure 15-11 on page 389.
4. Press Back
to return to the previous menu.
Figure 15-10 Example of a Maps *.zip Being Recalled From a USB Storage Device
For FTP, refer to Using FTP with FieldFox and to the FieldFox Programming
Guide on www.keysight.com. See also, “How to Set Up Mapping When the
FieldFox Is On The LAN” on page 390.
