Keysight N9927-90001 User’s Guide 387
On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on
N991xB), GPS (Option 307) and GPS Receiver (Option 307))
Downloading and Using the FieldFox Map Support Tool
5. Saving your *.zip file to a storage device and importing your *.zip to the
FieldFox:
a. Insert an SD card or USB storage device into your PC.
b. Open the PC’s Downloads folder and find your *.zip file. (e.g.,
MapsZIP_Example_1). Refer to Figure 15-9 on page 387.
c. Find your maps *.zip file.
d. Copy the *.zip file to your SD card or USB storage device.
e. Remove the SD card/USB storage device from your PC.
f. Insert the SD card/USB storage device into the FieldFox.
Figure 15-9 New Maps Zip File – MapExample_1
For FTP, refer to Refer to Using FTP with FieldFox and to the FieldFox Programming
Guide
one www.keysight.com.
IMPORTANT!
In the folder that contains your unzipped files, do NOT change any of the
Map file folders or filenames. Doing so will prevent the FieldFox from being
able to recognize the map files.
New downloaded Map folders, for the same map locations and zoom
levels, will overwrite any existing folders on the FieldFox.
