Keysight Handheld Analyzers
N99xxA User’s Guide
11 IQ Analyzer (IQA) – Option 351 (CPU2 Only)
IQA mode measures signals at the SA RF IN connector.
IQA mode requires the FieldFox to have SA mode and CPU2 installed.
Figure 11-1 IQ Analyzer (IQA) Display - LTE–TDD signal captured using the FieldFox’s I/Q
analyzer
The FieldFox can be used with an OML frequency extender. Refer to
“Utilities” on page 630, the A Series FieldFox Configuration Guide
5990-9836EN, and to “Contacting Keysight” on page 5.
