Keysight Technologies FieldFox N9938A User Manual

428 Keysight N9927-90001 User’s Guide
Interference Analyzer (SA Mode) – Option 236
Record/Playback (SA Option)
To view and edit the maximum number of records
Just after opening or initiating a session...
—Press Session Data
—Then TraceRecordLimit <n>
(n = Max number of traces that can be
recorded).
— Clear All Records
Empties that session of recorded traces. Learn more in
“Manage Sessions” on page 435.
FieldFox Setting Changes during Record and Playback
During Recording
When any of the following State settings are changed during recording, the
State counter is incremented (“About State and User Tags” on page 429) and
the settings are saved to the Session file along with the first trace to be
recorded with the new setting. During playback, the trace and display
annotation will reflect the change on the screen.
State settings:
Refer to Table 17-1 for a list of the applicable state settings for the SA option.
Table 17-1 Summary of SA State Settings
Option Settings
SA
Average Type
Detector(s)
External Gain
Frequency Range
Preamp On/Off
Resolution BW
RF Attenuation
Source Settings
Sweep Acquisition
Trigger Settings
Video BW
Zero Span Sweep Time

Keysight Technologies FieldFox N9938A Specifications

General

Dynamic Range	> 100 dB (typical)
Battery Life	4 hours
Tracking Generator	Yes
VSWR Measurement	Yes
Cable and Antenna Analyzer	Yes
Vector Network Analyzer (VNA)	Yes
Power Meter	Yes
GPS Receiver	Yes
Resolution Bandwidth (RBW)	1 Hz to 1 MHz
Measurement Functions	Return Loss, Cable Loss, Distance-to-Fault, Smith Chart, S-parameters, Spectrum Analysis
Operating Temperature	-10°C to +50 °C
Display	8.4-inch color touchscreen LCD
Storage Temperature	-40 to +70 °C
