377
Keysight Handheld Analyzers
N99xxA User’s Guide
15 On–the–Box Mapping – Option 352 (Requires Spectrum
Analyzer Mode (Option 233 on N991xB), GPS (Option
307) and GPS Receiver (Option 307))
Option 352 measures signals at the SA RF Input Port 2 connector.
Option 352 requires the FieldFox for outdoor mapping, GPS (Option 307)
installed. And, one of the following, an Over–the–air (OTA) mode (LTE FDD
Option 370, 5G TF Option 377, or 5G NR / 5G NR EVM Conducted Option 378),
or Channel Scanner mode (Option 312), IQA (Option 351), or Phased Array
Antenna (Option 360). Also, requires browser that supports HTML5 (i.e., web
browsers not supported: IE6, IE7, and IE8).
Recommended, but not required, preamplifier (Option 235) to improve receiver
sensitivity.
Keysight's FieldFox handheld analyzer (with Option 352) combined with a USB
triaxial antenna (p/o EMF Measurements – Option 358) provides a unique,
portable solution for indoor and outdoor maps in the field. Option 352 adds
indoor and outdoor mapping capability to FieldFox analyzers, so that FieldFox
can import maps from OpenStreetMap (OSM) for data collection and data
plotting to the map directly on the FieldFox instrument display. The FieldFox
indoor and outdoor mapping feature resides at the System level and the
mapping capability can be enabled within the following modes:
— Channel Scanner (Option 312)
— Phased Array Antenna Support (Option 360)
— Over-the-Air (OTA) LTE FDD (Option 370)
— Over-the-Air (OTA) 5G TF (Option 377)
— Over-the-Air (OTA) 5G NR (Option 378)
IMPORTANT!
85571A-028 (28 GHz 5G Phased Array Antenna) accessories not suitable
for use in wet locations.
B Model FieldFoxes measurements require an OML head
a
. Refer to
https://www.omlinc.com/.
a. Requires external mixer to down convert millimeter wave frequency to intermediate frequency (IF). Recommend
OML Inc. Contact OML directly www.omlinc.com for ordering information.
