392 Keysight N9927-90001 User’s Guide
On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on
N991xB), GPS (Option 307) and GPS Receiver (Option 307))
How to Set Up Mapping Settings
Option 352 Indoor Maps Setup Procedure
1. Set up your measurements in Channel Scanner, OTA, or Phased Array
Antenna. See also, Chapter 12, “Over–the–Air Measurements (OTA) – LTE
FDD Option 370 and 5GTF Option 377 (CPU2 Only),” and Chapter 26,
“Channel Scanner (Option 312).”
One or more are required:
— For setting up a phased array antenna, refer to Chapter 13, “5G
Rapid Prototype Phased Array Antenna – Option 360.”
— For setting up a USB antenna, refer to Chapter 14, “USB Antennas –
(Full Capability Requires EMF Option 358, and SA mode (Option 233
Mixed Analyzers)).”
Optional:
— For setting up GPS Option 307, refer to Chapter 29, “System
Settings,” and then “GNSS (GPS+) and GPS” on page 650.
2. Plan your Indoor Map:
a. Save mapping pictures to the FieldFox using USB storage device, SD
card, or connect to LAN with internet and download.
b. Import floor plans or site maps to the FieldFox from pictures (PNG,
JPG, and BMP).
Press System 7
> Mapping > Map Explorer (Get Maps)
c. Recommended: Do an interactive Walk Test data collection using
the location pointer.
3. If you are using an antenna with your measurements, then Connect your
equipment similar to Figure 1 on page 333 in Chapter 13, “5G Rapid
Prototype Phased Array Antenna – Option 360” or to Figure 14-1 on
page 366 in Chapter 14, “USB Antennas – (Full Capability Requires EMF
Option 358, and SA mode (Option 233 Mixed Analyzers))”.
4. Set up Record Playback: Optional: Auto-Save and distance/time or
Choose distance and manual drive or walk:
a. Press Record Playback
> Record Settings > Meas Interval ON then
— Press Interval Type Time Distance
(select one of these)
— Press Time Interval
(default = 10.0s) – 1.0s (minimum) to 3.5
ks (maximum) or
press Distance Interval
(default = 10.0m) – 1.0m (minimum to
10 km (maximum)
Importing floor plans can be imported now or after the indoor map
locations have been measured.
