N99xxA User’s Guide - Option 360 Phased Array Antenna
13 5G Rapid Prototype Phased Array Antenna – Option 360
Option 360 measures signals at the SA RF Input Port 2 connector.
Option 360 requires the FieldFox to have SA mode (Option 233 on combination
analyzers), and GPS (Option 307) installed.
Recommended, but not required, preamplifier (Option 235) to improve receiver
sensitivity.
Keysight's FieldFox handheld analyzer (with Option 360) combined with a Ball
Aerospace / Anokiwave 64-element antenna array provides a unique, portable
solution for measuring and analyzing the 5G air interface in the field.
— Reduce measurement complexity with integrated RF probe and phased
array solution to capture energy radiated from gNB
— Calibrated metrology milli-meter wave phased array antenna simulates 5G
UE antenna performance
— Troubleshoot the 5G radio access network with 3D test coverage and path
loss measurements utilizing the built-in CW generator
— Phased array performance verification showing bore sight, polar antenna
pattern with compass, heat map and beam sweep to map display views
In this Chapter
IMPORTANT!
85571A-028 (28 GHz 5G Phased Array Antenna) accessories not suitable
for use in wet locations.
PAA is compatible with the frequency converter heads, but cannot apply or
edit the frequency head corrections. Refer to “Utilities” on page 638.
The FieldFox can be used with an OML frequency extender. Refer to
“Utilities” on page 630, the A Series FieldFox Configuration Guide
5990-9836EN, and to “Contacting Keysight” on page 5.
“Using the Phased Array Antenna (Option 360)” on page 331
“About Phased Array Antenna Measurements” on page 332
