356 Keysight N9927-90001 User’s Guide
5G Rapid Prototype Phased Array Antenna – Option 360
How to Set Up Phased Array Antenna Settings
— Edit Cable
— New
— Save Cable
— Recall Cable
— Storage Device
2. Press Scale/Amptd
then choose:
— Autoscale
— Unit dBm
— External Gain
— External Gain
Step 6: Enable Recording and Record Data Logging Results
GPS must be enabled for the log results to include a GPS stamp or use
Preferences to enable the timestamp. Refer to Chapter 29, “System Settings.”
Features
— Log files contain cell results for different component carriers (CCs)
including timestamps and/or distance stamps.
— Timestamps are included in log files with or without GPS.
— GPS must be enabled for log altitude results.
—Data results can be logged
— Data results can be saved to a *.CSV or *.KML file. Refer to “” on page 358.
— User specifies how often results are stored.
— Time: Store results every “n” seconds
— Altitude: Store results every “n” meters. GPS must be enabled to
store results by altitude.
Procedure
1. Press Measure 1 > Data Logging > Record Settings > Meas Interval ON
2. Press Interval Type
> Time (default) or Distance then:
— Time Interval
1 sec to 999 seconds or
— Distance Interval
from 1m to 10 km
Spectrum and Strip Chart information is not recorded. Only the Table and
Bar Chart data are saved. See “How to Record” on page 360.
