408 Keysight N9927-90001 User’s Guide
On–the–Box Mapping – Option 352 (Requires Spectrum Analyzer Mode (Option 233 on
N991xB), GPS (Option 307) and GPS Receiver (Option 307))
How to Record/Playback (Option 352)
—Then Data Logging > Save Recall Rec-Playback
—Then Recall Logs use the Use the RPG or the arrow keys to
highlight the file to be played.
——Then Recall File
——Then Back
—Then Play
to playback your Table data.
is displayed in the left of screen graticules during playback. When the
end of the recording is reached, playback begins at the start of scan and
continues to loop indefinitely.
During playback, choose from the following:
— Pause Resume
Temporarily halts playback. Then choose from the following:
— Pause Resume
Press to continue playing.
— Stop
Immediately stops playback. Then choose from the following:
— Play
Start playback from start of scan.
— Recall Logs
Opens a list of stored data files.
Select a file to playback.
— Recall File
— Back
— Cursor Position
use this softkey to move the data log play cursor in the
current data log being played.
This softkey is only available in Channel Scanner and Phased Array Antenna
modes (i.e., The Cursor Position softkey is not available for OTA mode).
— Red Limit
to edit the red limit dBm value.
— Blue Limit
to edit the blue limit dBm value.
If these are large recordings on a device, it could take several seconds for
the FieldFox to display the list.
