KIP 5000 - Specifications

Section 1 Basic Printer Functions 1-6
1. 4 Specifications
Item Specification
Model KIP 5000
Configuration Console
Printing method LED Array Electro Photography
Photoconductor Organic Photoconductive Drum
Print speed 3.9 inches per second (100mm / sec)
(4 E size or 8 D size in one minute)
Resolution 600dpi
Print width Maximum width 36 inches
Minimum width 11 inches (Roll Media)
8.5 inches (Cut Sheet Paper)
Print length Maximum length 6m - 19.7 ft (Standard)
24m - 78 ft or unlimited (Optional)
Minimum length 8.5 inches
NOTE : If the print is longer than 6m, we can not guarantee image
quality or the reliability of media feeding systems.
Warm up time Less than 8 minutes
(At 74 degrees Fahrenheit 23 degrees Centigrade, 60% RH and
120V / Plain Paper)
First print time 24 seconds / E size (Roll 1)
Fusing method Heat Roll Fusing
Development method Dry, non-magnetic, mono-component toner
Exposure method LED
Charging method Corona
Transfer method Corona
Separation method Corona
Media feeding method 1. Automatic (2 Roll Decks) + Manual Bypass
2. Automatic (4 Roll Decks) + Manual Bypass
Input power 120V plus or minus 10%, 16A and 50/60Hz
Average power
consumption
Dehumidify Heater is ON
0.7kwh (Stand by) / 1.5kwh (Printing)
Power Saving Mode 98wh (Cold Sleep Mode)
Acoustic noise Less than 52db (Stand by) / Less than 60db (Printing)
Ozone Smaller than 0.1ppm (Average)
Dimensions 1,365mm (W) x 700mm (D) x 900mm (H) 53”W x 27”D x 35”H
Weight 230kg or 510 lbs (2 Roll Model)
270kg or 595 lbs (4 Roll Model)
Media Plain Paper Bond 18 – 24 lbs
Vellum Vellum 18 – 20 lbs
Film 3.5 or 4 MIL
Environmental condition Temperature 10 to 32 degrees Centigrade (32 to 89 F) and
within the humidity range of 20 to 80% RH.
NOTE : 1. The above specifications may change without notice.
2. [Storage of Consumables]
Media Wrap the media securely to keep out moisture.
Toner Store the cartridge within the temperature range of 0 to 35 degrees
Centigrade ( 32 to 95 F ) and within the humidity range of 10 to 85% RH.
