Section 1 Basic Printer Functions 1-10
Job Info Screen
No. Name Function
1 Mode Selects the “Mode” of the system. (Job Mode for this
screen shown)
2 User Name – Job # Display the User and any user info of the job ID. A job
can be selected for other functions noted below.
3 Media Information Displays Width, Type and amount remaining per roll deck
4 Status Shows the current status of a job and media selection.
5 Type Displays a copy or network print job
6 Total Displays the total number of prints and current number
printed.
7 To Top After a job is selected (see #2) its position in the queue
can be changed, making it the next job printed.
8 Pause Pauses printer to allow media change, etc
9 Delete After a job is selected (see #2) it can be removed from
the print queue.
10 Up/Down Scrolls through pages in the queue if so available.
1
3
2
4 5 6
8
7
9
10
