KIP 5000 - 4.0 Error Correction

Section 1 Basic Printer Functions
1-56
4. 0 Error Correction
4. 1 Paper Mis-feed Errors
If a paper mis-feed occurs, the Paper Mis-feed Indicator on the Sub Display and a screen on the
Touchscreen inform you of the error and the location. The Sub Display indicates a mis-feed code
(J-XX) to let you know where the paper is mis-fed. The Touchscreen will describe the location and
supply a guide on the screen.
Refer to the following diagram for the location of the paper mis-feed indicated by the code on the
Sub Display (Greater details on each code are on the following pages.)
MENU ENTE R TEST
TONER REMAIN IMAGE DENSITY
job
Paper Mis-feed Error
Paper Mis-feed Code
J-01 (Paper Mis-feed in the Roll 1)
Outer Device
(Auto Stacker,
Folder, etc.）
J-21, J-22
J-13, J-14
J-12 J-11
Roll 1
Roll 2
Roll 3
Roll 4
Front Rear
J-05
J-10
J-01
J-02
J-03
J-04
OR
