Chapter 6
Parts Lists
Introduction
The parts lists included in this chapter cover all models of the K2600 Series. Some printed circuit
boards and assemblies are used in more than one model. Therefore, the parts lists on the
following pages are listed under these headings:
The following two tables list the printed circuit boards and assemblies by model.
Note: The K2600/K2600S/K2600X/K2600XS/K2600 AES have been combined as these models
share most printed circuit boards and assemblies in common. The exceptions are the parts lists
for the LCD Board and the Final and Keyboard Assemblies.
K2600R, K2600RS
K2600 Series All Models
K2600R/K2600RS Rack Models
K2600 Series Keyboard Models All Keyboard Models
K2600/K2600S All 76-Note Keyboard Models
K2600/K2600X/K2600 AES All 88-Note Keyboard Models
Part No. Description Page
N012000134 Final Assembly page 6-11
N012103796 LCD Board page 6-7
N012104121 AC Entry Module Assembly page 6-8
N012104325 Backlight Inverter Board page 6-7
N012104665 Floppy Disk Drive Assembly page 6-7
N012304340 Power Supply Board page 6-8
N012305411 CPU Board page 6-3
N012305413 DSP Board page 6-5
N012305417 Front Panel/Scanner Board page 6-10
N012305605 Audio Board page 6-6
N012401127 Phone & Volume Assembly page 6-8
