6-16
Parts Lists
K2600 Series Keyboard Models
Super Ribbon Assembly, N044011513
Pitch & Mod Wheel Assembly, N012304338
Player Control Board, N012104337
Part No. Description Qty. Reference Designation
N041021551 CONNECTOR FFC/FPC GVERSION (15-38-8050) 1
N044011511 SUPER RIBBON CONTROLLER K2500 1
Part No. Description Qty. Reference Designation
N013025904 CABLE PITCH & MOD WHEEL K2500/X 1
N051102301 POT ROTARY 10K (K2000) 2
N032021811 BUSHING 8.0X26K2000 1
N032021911 SPRING TORSION MUSIC WIRE 1
N032037311 BRACKET PITCH & MOD WHEEL MOUNTING 1
N035020311 PITCH & MOD WHEEL 1
N044011411 CHEEK BLOCK RIBBON CONTROLLER K2500 1
N035028114 CHEEK BLOCK K2600 1
N035028113 CHEEK BLOCK (WD GR) BF K2500AES
Part No. Description Qty. Reference Designation
N025323304 MACHINE SCREW BH M3X4 BLK 4 SCREW
N032037511 BRACKET PLAYER CONTROL PCB MOUNTING 1 BRACKET
N041030004 HEADER .1" SP 4P (22-27-2041) 1 J404
N041033104 HEADER .1" SP WHITE R/A 4P 1 J403
N041034005 HEADER .098" SP 5P (22-03-5055) 1 J406
N041034006 HEADER .098" SP 6P (22-03-5065) 1 J402
N041034010 HEADER .098" SP 10P (22-03-5105) 1 J401
N041034120 FCC/FPC ZIF CONN 0.1" SP 5P MOLEX 1 J405
N051100103 RES CF 10Ω 5% 1/8W 1 R11
N051100110 RES CF 91Ω 5% 1/8W 1 R10
N051100115 RES CF 150Ω 5% 1/8W 2 R33, 34
N051100132 RES CF 1KΩ 5% 1/8W 1 R6
N051100134 RES 1.5KΩ 1/8W 5% 1 R32
N051100138 RES CF 2.2KΩ 5% 1/8W 2 R9, 31
N051100145 RES CF 4.7Ω 5% 1/8W 1 R36
N051100157 RES CF 10Ω 5% 1/8W 4 R16, 20, 29, 30
N051100161 RES CF 20KΩ 1/8W 5% 1 R35
N051100179 RES CF 100Ω 5% 1/8W 9 R1-4, 7, 8, 12, 14, 18
N051100182 RES CF 200KZ 5% 1/8W 1 R19
N051100183 RES CF 150K 1/8W 5% 1 R5
N051100191 RES CF 240KΩ 5% 1/8W 4 R22, 23, 26, 27
N051100208 RES CF 390KΩ 5% 1/8W 2 R24, 28
To Next Page
