Kurzweil K2600 Series User Manual

6-14
Parts Lists
K2600 Series Keyboard Models
Button Board, N012304344
Control Panel Board, N012104341
N052007503 CAP CER X7R 0.1UF 50V 10% 1206 75 C1, 3, 7-10, 14, 15, 27, 28, 69, 71, 73, 74, 78, 79, 130-187, 189
N052080012 CAP CER NPO 68PF 50V 2% 0805 8 C45-48, 105-108
N052080015 CAP CER NPO 150PF 50V 2% 0805 8 C57-60, 117-120
N052080022 CAP CER NPO 220PF 50V 5% 0805 8 C11-13, 16, 75-77, 80
N052080023 CAP CER NPO 180PF 50V 2% 0805 8 C33-36, 93-96
N052080027 CAP CER NPO 270PF 50V 2% 0805 8 C37-40, 97-100
N052080039 CAP CER NPO 1000PF 50V 2% 0805 8 C61-64, 121-124
N052080047 CAP CER NPO 2200PF 50V 1% 0805 32 C29-32, 41-44, 53-56, 65-68, 89-92, 101-104, 113-116, 125-128
N052080056 CAP CER NPO 47PF 50V 2% 0805 8 C49-52, 109-112
N053000703 DIODE RECT GP SMT 1A S1A SMA 1N4001 1206 1 D3
N053000802 DIODE SWITCH 1N4148 SMT DL-35 2 D1, 2
N054000802 TRANS MMBT2222L SOT-23 1 Q1
N061016302 IC LOGIC 74HC139 SOP16/16W 1 U1
N064003508 IC ANA OPAMP DL BIP LO-NOIS NE5532A 29 U4-11, 14-34
N263010310 IC AD1865R SOP24 4 U2, 3, 12, 13
Part No. Description Qty. Reference Designation
N013027902 CABLE BUTTON BOARD 640M/M K2600 1
N043010201 SWITCH TACK 6mmX3.5mm 160GF ALPS SKHLAC 2
N045010111 LED T1 RED HI EFF DIFFUSED LTL-4221 2
N035026139 LARGE BUTTON W/LED (9) K2600 1
N035026140 LARGE BUTTON W/LED (10) K2600 1
Part No. Description Qty. Reference Designation
N013025103 CABLE FRONT PANEL 880MM K2600X 1
N013025903 CABLE ASSY CONTROL/SLIDER 51M/M K2500/X 1
N035026101 LARGE BUTTON W/LED PC-88 10
N035026217 LARGE BUTTON NO LED PC-88 11
N035026244 LARGE BUTTON W/LED (3) (1,2,3) K2600 1
N035026245 LARGE BUTTON W/LED (3) (4,5,6) K2600 1
N035026246 LARGE BUTTON W/LED (3) (7,8,9) K2600 1
N035026247 LARGE BUTTON W/LED (3) (+/-, 0, CLEAR) K2600 1
N035026248 LARGE W/LED (1) (CANCEL) K2600 1
N035026249 LARGE BUTTON W/LED (1) (ENTER) K2600 1
N035026250 LARGE BUTTON W/LED (1) (<_>) K2600 1
N035026251 LARGE BUTTON W/LED (1) (<_>) K2600 1
N035026252 LARGE BUTTON W/LED (1) (<_>) K2600 2
N035026253 LARGE BUTTON W/LED (1) (<_>) K2600 2
N035026711 SPIN KNOB BEZEL PC-88 1
Part No. Description Qty. Reference Designation

Kurzweil K2600 Series Specifications

General

Polyphony	48 voices
Multitimbral	16 parts
MIDI	In, Out, Thru
Type	Workstation
Synthesis Method	VAST (Variable Architecture Synthesis Technology)
Keyboard	61, 76, or 88 keys
Sequencer	16-track sequencer
Display	LCD
Sampling	Yes, with optional sampling option
Storage	Floppy disk
Audio Outputs	Stereo outputs
Audio Inputs	Stereo inputs
