Kurzweil K2600 Series User Manual

4-30
K2600/K2600X Disassembly/Assembly
K2600X Keyboard Assembly
Natural/White Key
Figure 4-14 Natural/white key, 88-note keyboard
Figure 4-15 Sharp/black key, 88-note keyboard
Natural/White Keys
1. Remove the silver key spring located at the rear of the key. You will notice that the bottom
of the spring is secured to the keyboard chassis by a hook.
You can remove the spring by inserting a dowel (3mm diameter) into the spring, and
pushing down on it slightly. Then pull the top of the dowel toward the front of the
keyboard. This will unhook the spring from the keyboard chassis.
Strikes the front and rear key
contact on key depression
Mounts through the
keyboard chassis
Key spring
location
Pivot
location
Hooks under the front
of the keyboard chassis
Strikes the front and rear key
contact on key depression
Mounts through the
keyboard chassis
Key spring
location
Pivot
location
Hooks under the front
of the keyboard chassis

Kurzweil K2600 Series Specifications

General

Polyphony	48 voices
Multitimbral	16 parts
MIDI	In, Out, Thru
Type	Workstation
Synthesis Method	VAST (Variable Architecture Synthesis Technology)
Keyboard	61, 76, or 88 keys
Sequencer	16-track sequencer
Display	LCD
Sampling	Yes, with optional sampling option
Storage	Floppy disk
Audio Outputs	Stereo outputs
Audio Inputs	Stereo inputs
