Parts Lists
K2600R/K2600RS
6-11
Final Assembly, N012000134
N052901610 CAP ELECT GP 10UF 16V 20% SZB SMT 1 C3
N053000802 DIODE SWITCH 1N4148 SMT DL-35 1 D10
N054000802 TRANS MMBT2222L SOT-23 2 Q1, 3
N054002906 TRANS MMBT2907L SOT-23 2 Q2, 4
N061000302 IC LOGIC 74LS145 SOP16 1 U3
N061020203 IC 74HC74A DUAL D-FLOP SOIC14 1 U2
N235023601 LED SPACER LH-3-6 1 @D9
N262100607 IC MICROCONTROLLER M37451M8-727FP 1 U1
Part No. Description Qty. Reference Designation
N013030951 CABLE TIE 8
N013039102 CABLE POWER SUPPLY TO ENGINE 200MM 1
N013039202 CABLE POWER SUPPLY AUDIO 200MM K2600R 1
N013039402 CABLE POWER SUPPLY TO INVERTER 170MM 1
N013039602 CABLE SCAN TO POWER SUPPLY 330MM 1
N013039801 CABLE FAN POWER 260MM K2600/X/R 1
N013040002 CABLE ENGINE TO AUDIO 300MM K2600R 1
N013040103 CABLE ENGINE TO SCAN 330MM K2600R 1
N015000123 TRANSFORMER ASSY K2600R 1
N022002701 EDGE-HOLDING SUPPORT 7.9mm 5
N022002702 BUTTON SUPPORT DONG-A DABS12R 3
N022002703 SPACER PUSH LOCKING 8.0MM TALL 2
N022003714 CABLE CLAMP 14P 2
N022003716 CABLE CLAMP 16P 2
N022003720 CABLE CLAMP 20P 1
N022003734 CABLE CLAMP 34P 2
N025223408 TAPPING SCREW-2 BH M3X8 BLK (SMALL) 1
N025313307 MACHINE SCREW FH M3X6 BLK 6
N025323306 MACHINE SCREW BH 3X6 BLK 46
N025323308 MACHINE SCREW BH M3X8 BLK 1
N025323310 MACHINE SCREW BH M3X10 BLK 2
N025323408 MACHINE SCREW BH M4X8 BLK 9
N025353306 MACHINE SCREW TH M3X6 BLK 2
N025353335 MACHINE SCREW TH M3X35 BLK 4
N025353404 MACHINE SCREW TH 4X4 BLK 2
N025353408 MACHINE SCREW TH M4X8 BLK 6
N025683316 SET SCREW 3X16 BLK 1
N025693320 HEX SPACER BH M3X20BLK 6
N025693322 SCSI BOLT (WHITE) 8
N025874302 NUT M3 DIN934 6
N025874303 NUT M4 4
N027112100 FLAT WASHER 3.3X6.5X0.5 4
N027113160 FLAT WASHER 4.5X10X0.5AN 4
Part No. Description Qty. Reference Designation
To Next Page
