K2600/K2600X Disassembly/Assembly
K2600 Keyboard Assembly
4-23
Disconnecting the K2600 Keyboard
Follow this procedure if you are merely replacing one or more keys.
1. Refer to Figure 4-8.
2. Tilt the K2600 up and remove the four keyboard rear screws, then lay the K2600 flat on
your work surface.
3. Move the K2600 forward so that the front hangs over the edge of your work surface,
giving you access to the remaining screws.
4. Remove the four keyboard front screws.
Caution: The keyboard Aftertouch flex cable from the keyboard is connected to the Mod
Wheel Assembly and is secured to the bottom enclosure with reinforced tape. When
following the instructions below, be certain that you only slightly lift or move the
Keyboard Assembly, to avoid damage to the flex cable.
5. The 16 screws that secure the keyboard to the wooden spacer rest in holes provided for
them on the bottom enclosure. To move the keyboard, lift the keyboard up slightly to free
the 16 screws from their positions on the bottom enclosure.
6. Lift the keyboard up slightly and move it approximately one inch to the right (as viewed
standing at the keyboard).
7. You can now move the keyboard back approximately one inch toward the rear panel so
that you can remove keys for replacement. See page 4-24 for procedures for removing and
replacing keys.
Connecting the Keyboard
1. Position the keyboard so that the 16 screws that secure the wooden spacer to the keyboard
are resting in the holes provided for them on the bottom enclosure.
Caution: Be certain that the Aftertouch flex cable is correctly positioned and that the
nylon reinforced tape securing it to the bottom enclosure is still properly applied.
2. Refer to Figure 4-8.
3. Move the K2600 forward so that the front hangs over the edge of your work surface, and
install the four keyboard front screws.
4. Slide the K2600 back onto your work surface.
5. Tilt the K2600 up and install the four keyboard rear screws.
