Parts Lists
K2600 Series Keyboard Models
6-17
AC Entry Module, N012104111
Power Supply Board, N012304339
N051101411 POT 50K 3/4 TURN TOP/BOT EVN-D8AA03B54 3 R13, 15, 17
N051101412 POT 100K 3/4 TURN TOP/BOT EVN-P8AA03B15 2 R21, 25
N052001204 CAP CER MONO Z5U .1UF 50V 20% .3AX 5 C1-4, 7
N052001210 CAP CER MONO 0.022UF 50V Z5U 2 C5, 6
N053000401 DIODE 1N270 2 D1, 2
N053000701 DIODE 1N4001 DO-41 1 D7
N053000801 DIODE 1N4148 DO-35 8 D3-6, 8-11
N054000101 TRANSISTOR GP NPN 2N3904 TO-92 1 Q2
N054000201 TRANSISTOR 2N3906 1 Q3
N054001201 TRANSISTOR PNP KTA1271 (KSA643CY) TO-92 1 Q1
N061008110 IC 74HC4051 DUAL MUX DIP16 1 U2
N064001903 IC LINEAR OPAMP TLC2272CP DIP8 3 U3-5
N064010030 IC LM339 QUAD COMP DIP14 1 U1
Part No. Description Qty. Reference Designation
N013026090 CABLE ASSY AC ENTRY POWER 190M/M K2500/X 1
N013026091 CABLE ASSY AC ENTRY GROUND 300M/M K2500/X 1
N051101114 RES CF 56Ω 5% 1W METAL OXIDE 1
N052003529 CAP METALIZED FILM 0.47UF 250V 1
N241033601 POWER MODULE 5EFM4S 1
N043010604 FUSE SLOW-BLOW 250V 1.25A 5X30MM 1
N043010605 FUSE TIME-LAG 250V 0.63A 5X20MM (EUROPE) 2
Part No. Description Qty. Reference Designation
N013039203 CABLE ADD POWER SUPPLY K2600/S/X/XS/R/RS 1
N025224508 TAPPING SCREW-2 BH 3.5X8 WHITE W/WASHER 10
N025323408 MACHINE SCREW BH M4X8 BLK 2
N032020435 CLAMP COMP-HEAT SINK 3-GANG TO220-TO180 1 @D3, Q2, 3
N032020436 CLAMP COMP-HEATSINK 2-GANG TO220-TO218 2 @VR1, 2, 5, 6
N032031001 RG-X HEATSINK SUPPORT BRACKET 2
N032055402 HEATSINK K2600/X 1
N032059601 BRACKET GROUNDING HEAT SINK K2600/X 2
N041025302 HEADER .156SP 2P (09-65-2028) 1 J102
N041025305 HEADER .156" SP 5P (09-65-2058) 1 J107
N041025306 HEADER .156" SP 6P (09-65-2068) 1 J101
N041025308 HEADER .156" SP 8P (09-65-2088) 1 J105
N041034002 HEADER .098" SP 2P (22-03-5025) 1 J103
N041034003 HEADER .098" SP 3P (22-03-5035) 1 J104
N041034004 HEADER .098" SP 4P (22-03-5045) 1 J106
Part No. Description Qty. Reference Designation
