K2600R Disassembly/Assembly
Front Panel Assembly
3-19
2. From the Optical Inputs section of the front panel, remove the cap from the Optical jack.
3. Remove the nut and washer from Analog Input 1/4” jack.
4. Remove the four screws (use a #1 screwdriver) from the Analog Input XLR jacks.
5. Slide the board back toward the rear panel to free the jacks from the front panel cover, and
lift the back end of the board (closest to the rear panel) to remove the Sampling Board.
Replacing the Sampling Board
1. Tilt the front end of the Sampling Board down and place the board in position. Be sure
that the jacks are correctly aligned through the openings provided for them in the front
panel cover.
Note: You will notice a rubber bumper located on the bottom enclosure. This helps
protect and position the bottom edge of the Sampling Board.
2. Install the four screws (use a #1 screwdriver) that secure the Analog Input XLR jacks.
3. Install the nut and washer that secure the Analog Input 1/4” jack.
4. Install the cap onto the Optical jack.
5. Connect the cables listed in Table 3-6. Be sure to install the locking cable clip on the flat
ribbon cable.
