6-2
Parts Lists
Introduction
K2600, K2600S, K2600X, K2600XS, K2600 AES
Part No. Description Page
N012000133 Final Assembly (K2600X/K2600XS/K2600 AES) page 6-24
N012002131 Final Assembly (K2600/K2600S) page 6-21
N012103794 LCD Board (K2600/K2600S) page 6-21
N012103798 LCD Board (K2600X/K2600XS/K2600 AES) page 6-24
N012104111 AC Entry Module Assembly page 6-17
N012104311 Backlight Inverter Board page 6-15
N012104337 Player Control Board page 6-16
N012104341 Control Panel Board page 6-14
N012104345 Slider Board page 6-20
N012104666 Floppy Disk Drive Assembly page 6-15
N012304338 Pitch & Mod Wheel Assembly page 6-16
N012304339 Power Supply Board page 6-17
N012304344 Button Board page 6-14
N012305411 CPU Board page 6-3
N012305413 DSP Board page 6-5
N012305415 Keyboard Scanner Board page 6-19
N012305611 Audio Board page 6-13
N044011513 Super Ribbon Assembly page 6-16
N215040311 Keyboard Assembly 76-Note page 6-23
N215040413 Keyboard Assembly 88-Note page 6-26
