Parts Lists
K2600 Series
6-5
DSP Board, N012305413
N083015701 IC MASKROM K2501 BASE ROM 64M 830157-001 1 U32
N083015801 IC MASKROM K2600 PIANO 32M 830158-001 1 U33
N261000244 IC DIG 74LCX244 OC BUS XCEIVER 3-ST 1 U26
N261008245 IC DIG 74LCX245 OC BUS XCEIVER 3-ST 4 U25, 27, 30, 31
N262001300 IC MICROCONTROLLER 68340FE-25B, 25MHz 1 U3
N263010201 IC SCSI BUS CONTROLLER L53C80JC2 PLCC44 1 U14
N263010210 IC SCSI TERMINATOR 18-LINE UC5608QP 1 U15
N266000702 IC JAINS B VY06688 2 U17, 18
Part No. Description Qty. Reference Designation
N041031240 CONN .1" SP DUAL ROW 40P (057-040-153) 1 J901
N041031280 CONN 0.079" SQR .157 GLD 50P MOLEX 2 J903
N041033374 SOCKET IC PLCC SMT 84POS 822281-1 1 @U14
N042005405 JUMPER WIRE 5MM 1 J902 (PIN 1 & 2)
N051001014 RES NET ISO 51X4 5% 1/10W 5.08mmX2.2mm 19 RP1-19
N051101718 RES CF 220Ω 5% 1/8W 1206 4 R1, 2, 6, 10
N051101720 RES TF 330Ω 5% 1/8W 1206 4 R3, 4, 7, 11
N051101730 RES CF 1.0KΩ 5% 1/8W 1206 18 R5, 12-17, 71, 72, 113-120, 122
N051101790 RES CF 1.0MΩ 5% 1/8W 1206 2 R8, 121
N052002422 CAP ELECT 470UF 6.3V 3.5mm SP.11mm 1 C115
N052005105 CAP ELECT 100UF 10V RAD 1 C116
N052007005 CAP CER NPO 27PF 50V 5% 1206 2 C117, 122
N052007006 CAP CER NPO 6.8PF 50V 5% 1206 1 C121
N052007503 CAP CER X7R 0.1UF 50V 10% 1206 86 C1-27, 32-37, 40-57, 59-64, 74-77, 99-114, 118-120, 123-128
N055004301 EMI FILTER DUAL EXC-EMT470BT 1 L7
N059010012 XTL 19.9680MHZ +/- 50PPM FND PAR 32PF SMT 1 Y1
N061000901 IC DIG NC7S04 TINY INV SOT23-5 1 U41
N061000910 IC DIG NC7SU04 TINY UNBUF INV SOT23-5 1 U33
N061000913 IC TINY LOGIC NC7SZ04 SOT23-5 3 U1, 7, 34
N061007138 IC LOGIC 74VHC138 SOP16/16W 2 U39, 40
N061007245 IC LOGIC 74VHC245 SOP20 4 U35-38
N061011008 IC LOGIC 74AC08 SOP14-150 1 U4
N062100416 IC MEMORY DRAM 1MX16 70nS(max) SOJ42 4 U25-28
N266000302 IC HOBBES VY05293 4 U2, 3, 5, 6
N266000801 IC LISA VY06514 PLCC84 4 U8, 10, 11, 13
Part No. Description Qty. Reference Designation
