Kurzweil K2600 Series User Manual

K2600/K2600X Disassembly/Assembly
Opening the K2600/K2600X
4-3
K2600X Bottom
1. Refer to Figure 4-2. Remove the enclosure support wall screws and the endblock locking
bracket screws (not the endblock screws). Arrows show the locations of the enclosure
support wall and endblock locking bracket screws.
Note: Do not remove the five endblock screws at this point.
2. Tilt the K2600X up and remove the eight enclosure support wall screws. These attach the
support wall to the bottom enclosure.
3. Remove the four endblock locking brackets screws (two on each side of the bottom
enclosure).
4. Slide the endblock locking brackets out of the K2600X and set them aside.
Note: The left and right endblock locking brackets are identical. Therefore, you don’t
need to keep them separate.
Figure 4-2 K2600X bottom enclosure
5. Place the K2600X flat on your work surface.
Access panel
Endblock screws
Endblock screws
Keyboard
Rear panel
Endblock locking bracket screws
Enclosure support wall screws

Kurzweil K2600 Series Specifications

General

Polyphony	48 voices
Multitimbral	16 parts
MIDI	In, Out, Thru
Type	Workstation
Synthesis Method	VAST (Variable Architecture Synthesis Technology)
Keyboard	61, 76, or 88 keys
Sequencer	16-track sequencer
Display	LCD
Sampling	Yes, with optional sampling option
Storage	Floppy disk
Audio Outputs	Stereo outputs
Audio Inputs	Stereo inputs
