4-22
K2600/K2600X Disassembly/Assembly
K2600 Keyboard Assembly
6. Slide the K2600 back onto your work surface.
7. Lift the Mod Wheel Assembly and disconnect the Aftertouch flex cable. This cable has
nylon reinforced tape securing it to the bottom enclosure. Peel back the tape from one side
to free the cable.
8. Place the Mod Wheel Assembly in its position on the bottom enclosure.
9. Remove the cable locking clip and disconnect the flat ribbon cable from the Keyboard
Scanner Board. This cable is also secured to the bottom enclosure with nylon reinforced
tape. Peel back the tape from one side to free the cable.
10. Remove the Keyboard Assembly.
11. The keyboard is mounted onto a wooden spacer. Sixteen screws secure the spacer to the
keyboard.
12. Lay the Keyboard Assembly upside down on a flat protected surface and remove the
16 screws. Remove the spacer and set it aside. The keyboard components are now
accessible for maintenance and repair.
Replacing the K2600 Keyboard Assembly
Note: If you have disconnected the Bass and Treble ends of the flat ribbon cable from the
keyboard during service, be sure that you have reconnected them and reapplied the tape to
secure the connectors.
1. Place the keyboard upside down on a flat protected surface and position the wooden
spacer over the keyboard. Install the 16 screws that secure the wooden spacer to the
keyboard.
2. Place the Keyboard Assembly on the bottom enclosure. Be sure that the flat ribbon cable
from the keyboard is correctly positioned.
3. Connect the flat ribbon cable to the Keyboard Scanner Board and reapply the cable locking
clip. Be sure to reapply the nylon reinforced tape that secures the flat ribbon cable to the
bottom enclosure.
4. Lift the Mod Wheel Assembly and connect the Aftertouch flex cable. Place the Mod Wheel
Assembly in its position on the bottom enclosure. Be sure to reapply the nylon reinforced
tape that secures the flex cable to the bottom enclosure.
5. Move the K2600 forward so that the front hangs over the edge of your work surface, and
install the four keyboard front screws.
6. Install the four Mod Wheel Assembly screws and washers.
7. Slide the K2600 back onto your work surface.
8. Tilt the K2600 up and install the four keyboard rear screws.
