Kurzweil K2600 Series - Phone & Volume Assembly, N012401127; AC Entry Module Assembly, N012104121; Power Supply Board, N012304340

6-8
Parts Lists
K2600R/K2600RS
Phone & Volume Assembly, N012401127
AC Entry Module Assembly, N012104121
Power Supply Board, N012304340
Part No. Description Qty. Reference Designation
N013040301 CABLE ASSY VOLUME TO AUDIO 380MM K2600R 1
N041034501 PHONE JACK STEREO 1/4" RA49C-14B 1
N051101605 POT ROTARY VOLUME 10K CPSG-1604 1
N052005300 CAP CER MONO 470PF 200V 5% NPO AX 2
N055002201 CHOKE COIL TRIPLE TORROID DLF3000 1
Part No. Description Qty. Reference Designation
N013026902 CABLE AC ENTRY POWER 260MM K2600R 1
N013040601 CABLE AC ENTRY GROUNDING K2600R 1
N013040701 CABLE POWER SWITCH K2600R 1
N025693321 HEX SPACER 5MM 2
N043010604 FUSE SLOW-BLOW 250V 1.25A 5X30MM 1
N043010605 FUSE TIME-LAG 250V 0.63A 5X20MM (EUROPE) 2
N043020101 POWER SWITCH 2000R 1
N051101114 RES CF 56Ω 5% 1W METAL OXIDE 1
N052003529 CAP METALIZED FILM 0.47UF 250V 1
N241033801 POWER MODULE 5EFM4 K2600R 1
Part No. Description Qty. Reference Designation
N013039203 CABLE ADD POWER SUPPLY K2600/S/X/XS/R/RS 1
N025224508 TAPPING SCREW 2 BH 3.5X8 WHITE W/WASHER 12
N025323408 MACHINE SCREW BH M4X8 BLK 2
N032020435 CLAMP COMP-HEAT SINK 3-GANG TO220-TO180 1 @D3, Q2, 3
N032020436 CLAMP COMP-HEAT SINK 2-GANG TO220-TO218 2 @VR1, 2, 5, 6
N032031001 RG-X HEATSINK SUPPORT BRACKET 2
N032055401 HEATSINK K2600R/RS 1
N041025302 HEADER .156" SP 2P (09-65-2028) 1 J102
N041025305 HEADER .156" SP 5P (09-65-2058) 1 J107
N041025306 HEADER .156" SP 6P (09-65-2068) 1 J101
N041025308 HEADER .156" SP 8P (09-65-2088) 1 J105
N041034002 HEADER .098" SP 2P (22-03-5025) 1 J103
N041034003 HEADER .098" SP 3P (22-03-5035) 1 J104
N041034004 HEADER .098" SP 4P (22-03-5045) 1 J106
N041034005 HEADER .098" SP 5P (22-03-5055) 1 J108
N049010102 INSULATION PAD 15X20MM W/O HOLE 3 @VR5, VR1, VR2
N049010110 INSULATION PAD (MICA PAD) 4 @D3, Q2, Q3, VR6
N051100103 RES CF 10Ω 5% 1/8W 5 R31, 36, 38, 39, 40
