Parts Lists
K2600R/K2600RS
6-9
N051100113 RES CF 100Ω 5% 1/8W 2 R17, 28
N051100115 RES CF 150Ω 5% 1/8W 1 R27
N051100117 RES CF 200Ω 5% 1/8W 2 R33, 37
N051100120 RES CF 330Ω 5% 1/8W 1 R32
N051100123 RES CF 510Ω 5% 1/8W 1 R34
N051100132 RES CF 1KΩ 5% 1/8W 5 R5-7, 18, 35
N051100137 RES CF 2KΩ 5% 1/8W 2 R10, 42
N051100141 RES CF 3KΩ 5% 1/8W 2 R24, 41
N051100145 RES CF 4.7Ω 5% 1/8W 4 R8, 13, 14, 23
N051100160 RES CF 15KΩ 5% 1/8W 3 R20, 21, 30
N051100256 RES MF 165KΩ 1% 1/8W 1 R25
N051100354 RES MF 10.0Ω 1% 1/8W 9 R1-4, 11, 12, 15, 16, 22
N051100359 RES MF 84.5KΩ 1% 1/8W 1 R19
N051100399 RES MF 499Ω 1% 1/8W 1 R29
N051100457 RES MF 357Ω 1% 1/8W 1 R26
N051101401 RES POT 100K 3/4 TURN 1 R9
N052001204 CAP CER MONO Z5U .1UF 50V 20% .3AX 13 C1-5, 7-8, 14, 15, 18, 19, 22, 28
N052001711 CAP ELECT 100UF 25V 20% RAD 2 C16, 17
N052001713 CAP ELECT 4700UF 25V 1 C9
N052002401 CAP ELECT 100UF 16V 20% .138 SP 5 C20, 21, 26, 27, 30
N052002414 CAP ELECT 220UF 16V 2 C6, 23
N052004204 CAP ELECT 2200UF 35V 20% RAD 2 C11, 12
N052005105 CAP ELECT 100UF 10V RAD 1 C29
N052005108 CAP ELECT 220UF 6.3V RAD 1 C24
N052005203 CAP ELECT 33000UF 16V 1 C10
N052005300 CAP CER MONO 470PF 200V 5% NPO AX 2 C13, 25
N053000701 DIODE 1N4001 DO-41 3 D2, 9, 11
N053000901 DIODE ZENER 5.1V 1N5231B 1 D10
N053001001 DIODE ZENER 6.1V 1N5234 1 D8
N053002201 DIODE MBR1535 1 D3
N053010001 DIODE KBU8B (8.0AMP) 1 D1
N053020101 DIODE AMP 1N4002(1A) 4 D4-7
N054000004 TRN PWR MOSFET IRFZ34N55V 0.04Ω 29A TO-220 2 Q2, 4
N054000602 TRANS PN2907 TO-92 1 Q1
N054000801 TRANS PN2222 TO-92 3 Q3, 5, 6
N064001502 IC LINEAR +5V LM7805 TO-220 2 VR5, 7
N064010001 IC LINEAR TL074CP DIP14 1 U1
N064010206 IC LINEAR KA78T12AC 1 VR6
N064010301 IC LINEAR VOLT REG +15 LM7815 (TO-220) 1 VR1
N064010401 IC LINEAR VOLT REG -15 LM7915 (TO-220) 1 VR2
N064010801 IC LINEAR +12V 7812 TO-220 1 VR3
N064010901 IC LINEAR -12V LM7912 TO-220 1 VR4
Part No. Description Qty. Reference Designation
To Next Page
