K2600/K2600X Disassembly/Assembly
K2600X Keyboard Assembly
4-29
Replacing the K2600X Keyboard Assembly
1. Place the keyboard on the bottom enclosure. Be sure that the flat ribbon cable from the
keyboard is correctly positioned to connect it to the Keyboard Scanner Board.
Note: If you have disconnected the Bass and Treble ends of the flat ribbon cable during
service, be sure that you have reconnected them and secured them with tape. Be sure that
the small ribbon cable connecting the Bass and Treble Contact Boards is connected.
2. Connect the flat ribbon cable to the Keyboard Scanner Board and reapply the cable locking
clip.
3. Secure the flat ribbon cable to the bottom enclosure with the nylon reinforced tape.
4. Lift the Mod Wheel Assembly and connect the Aftertouch flex cables. Be sure to reapply
the nylon reinforced tape that secures the flex cables to the bottom enclosure.
5. Slide the K2600X forward so that you can install the five keyboard front screws.
6. Install the four Mod Wheel Assembly screws.
7. Slide the K2600X back on to your work surface.
8. Tilt the K2600X up and install the four keyboard rear screws.
Removing Keys
The following procedure assumes you have removed the top enclosure from the K2600X.
1. Follow the procedure for removing the keyboard.
Note: If you are merely replacing one or more keys, it is not necessary to entirely remove
the keyboard from the K2600X. Once the keyboard is loose, you can slide it toward the
rear panel to give you enough access to remove keys.
2. The following diagrams illustrate the outlines of the natural and sharp keys and the
location and functions of the components described in the following procedures.
