Kurzweil K2600 Series User Manual

Parts Lists
K2600 Series
6-3
K2600 Series
CPU Board, N012305411
Part No. Description Qty. Reference Designation
N013041101 CABLE SAMPLE RAM POWER JUMPER K2600 1 @J819 PIN 2 & 3
N033120600 PCB FAB CPU BOARD (REV. D) K2600 1 PCB1
N035040105 BATTERY COINCELL 3V 195mah CR2032 1 B1
N035040202 BATTERY HOLDER TOSHIBA BH32 1 @B1
N041025206 HEADER .1" SP 6P (DUAL 3P) 1 J821
N041025303 HEADER .156" SP 3P (09-65-2038) 1 J819
N041025308 HEADER .156" SP 8P (09-65-2088) 1 J814
N041030111 CONN SOCKET .079" SPGLD 50P SQW-125-01-L-D 2 J812
N041030310 CONN MIDI JACK 3-GANG YKF 51-5041(JALCO) 1 J815
N041031210 CONN .1" SP DUAL ROW 14P (057-014-153) 1 J813
N041031216 HEADER .1" SP DUAL ROW 16P (057-016-153) 1 J808
N041031220 HEADER .1" SP DUAL ROW 20P (057-020-153) 1 J804
N041031234 HEADER .1" SP DUAL ROW 34P (057-034-153) 2 J801, 805
N041031250 CONN .1" SP DUAL ROW 50P (057-050-153) 1 J818
N041031268 CONN HIGH DEN 68P MALE FX2CA-68P-1.27DSA 1 J809
N041031279 CONN HDR DIP .079" SQR 8P 87089-0816 2 J802, JP803
N041032425 CONN DB PLST SHRT RAPC 25P 747846-3(-4) 2 J816, 817
N041033373 SOCKET SIMM 40 72P 15-82-0627 3 J803, 810, 811
N041034004 HEADER .098" SP 4P (22-03-5045) 1 J807
N043002141 POLYSWITCH 15V 2.0A .125Ω SMD 1 R162
N043010201 SW TACK 6mmX3.5mm 160GF ALPS SKHLAC 1 S3
N043010510 SW SLIDER R/A SPDT (ASC MHSS1105) 2 S1, 2
N051001007 RES NET ISO 10KX4 5% 1/10W 5.08mmX2.2mm 4 RP1-4
N051001014 RES NET ISO 51X4 5% 1/10W 5.08mmX2.2mm 6 RP5-10
N051064005 RES TF 56Ω 5% 1/16W 0603 19 R1, 3-8, 10-12, 14-17, 31, 64, 69, 70, 73
N051064010 RES TF 100Ω 5% 1/16W 0603 20 R9, 28-30, 88, 102-117
N051064012 RES TF 120Ω 5% 1/16W 0603 19 R128-146
N051064075 RES TF 75Ω 5% 1/8W 0603 1 R2
N051064110 RES TF 10Ω 5% 1/16W 0603 39 R19-27, 33-41, 77-81, 84, 89-91, 94, 97, 120-127, 149, 160
N051101287 RES TF 1.87KΩ 1% 1/8W 1206 1 R86
N051101293 RES CF 392Ω 1% 1/8W 1206 1 R147
N051101651 RES CF 150Ω 5% 1/8W 1206 1 R151
N051101700 RES CF 0Ω 5% 1/8W 1206 1 R164
N051101714 RES TF 110Ω 5% 1/8W 1206 11 R58, 60, 65-68, 71, 72, 74-76
N051101718 RES CF 220Ω 5% 1/8W 1206 4 R82, 92, 99, 118
N051101720 RES TF 330Ω 5% 1/8W 1206 4 R83, 93, 100, 119
N051101730 RES CF 1.0KΩ 5% 1/8W 1206 15 R18, 44-46, 53, 95, 96, 98, 101, 153, 156, 157, 159, 191, 192
N051101738 RES CF 2.2KΩ 5% 1/8W 1206 8 R47, 49, 55, 57, 59, 61, 63, 158
N051101741 RES TF 3KΩ 5% 1/8W 1206 3 R62, 165, 166
N051101745 RES CF 4.7KΩ 5% 1/8W 1206 5 R48, 50, 51, 56, 150
N051101747 RES TF 4.7MΩ 5% 1/8W 1206 1 R52

Kurzweil K2600 Series Specifications

General

Polyphony	48 voices
Multitimbral	16 parts
MIDI	In, Out, Thru
Type	Workstation
Synthesis Method	VAST (Variable Architecture Synthesis Technology)
Keyboard	61, 76, or 88 keys
Sequencer	16-track sequencer
Display	LCD
Sampling	Yes, with optional sampling option
Storage	Floppy disk
Audio Outputs	Stereo outputs
Audio Inputs	Stereo inputs
