Kurzweil K2600 Series User Manual

6-4
Parts Lists
K2600 Series
N051101748 RES TF 6.2KΩ 5% 1/8W 1206 1 R161
N051101780 RES CF 100KΩ 5% 1/8W 1206 1 R152
N051101785 RES CF 330KΩ 5% 1/8W 1206 1 R43
N051101790 RES CF 1.0MΩ 5% 1/8W 1206 1 R54
N051101799 RES CF 20MΩ 5% 1/8W 1206 1 R42
N052002420 CAP POLY .1UF 50V 1 C9
N052002422 CAP ELECT 470UF 6.3V 3.5mm SP.11mm 1 C98
N052003002 CAP ELECT 1000UF 10V 10MM 1 C37
N052004201 CAP ELECT 10UF 35V 20% .08SP 1 C100
N052004205 CAP ELECT 4.7UF 35V 1 C53
N052005105 CAP ELECT 100UF 10V RAD 1 C99
N052007001 CAP CER 15PF 50V NPO 1206 1 C41
N052007003 CAP CER 47PF 100V 5% NPO 1206 2 C43, 111
N052007004 CAP CER 1000PF 100V NPO 1206 10 C40, 44-52
N052007007 CAP CER 20PF 5% NPO 1206 2 C21, 22
N052007501 CAP CER 0.01UF 50V 10% X7R 1206 9 C74, 90, 93, 110, 115-119
N052007503 CAP CER X7R 0.1UF 50V 10% 1206 86
C1-8, 10-20, 23-36, 38-39, 42, 56-73, 75-89, 91-92, 94-97, 101-109, 112-
113
N052901022 CAP TAN CHP 22UF 6.3V 20% SZB SMT 1 C114
N052901047 CAP TAN CHP 4.7UF 6.3V 20% SZA SMT 2 C54, 55
N053000703 DIODE RECT GP SMT 1A S1A SMA 1N4001 1206 7 D4, 6-8, 10-12
N053000704 DIODE RECT GP SMT 1A S1J 600V SMA 1 D3
N053000802 DIODE SWITCH 1N4148 SMT DL-35 2 D5, 9
N053010503 DIODE 70V SCHOTTKY BAR SMD BAS70DICT 2 D1, 2
N054000102 TRANS KST3904 SOT-23 2 Q1, 2
N054000802 TRANS MMBT2222L SOT-23 3 Q3, 8, 9
N054002906 TRANS MMBT2907L SOT-23 2 Q4, 5
N054010101 TRANS PNP KSA931 1 Q6
N054010301 TRANS NPN KSC2331-Y 1 Q7
N055001508 IND FE BD SMT 1500mA 120Ω MI1812K121R 1812 4 L1, 4-6
N055004301 EMI FILTER DUAL EXC-EMT470BT 1 L2
N059010051 XTL 16.0000MHz +/- 50PPM FND PAR 18PF SMT 1 Y2
N059010071 XTL 32.7680KHZ +/-20PPM FND PA 12.5PF SMT 1 Y1
N061000913 IC TINY LOGIC NC7SZ04 SOT23-5 2 U16, 20
N061007245 IC LOGIC 74VHC245 SOP20 9 U8, 12, 28, 29, 34, 35, 37-39
N061007574 IC LOGIC 74VHC574 SOP20 3 U22-24
N061010302 IC LOGIC 74HCU04 SOP14 2 U36, 42
N061011004 IC LOGIC 74HC04 SOP14-150 1 U13
N061011245 IC LOGIC 74HC245 SOP20 1 U10
N062005512 IC MEM SRAM 512KX8 70nS SOP32-440 LOS 2 U6, 7
N062005525 IC MEM FLSH ROM 1MX16 70nS SSOP56-525 5V 2 U4, 5
N062006103 IC PLD GAL 22V10 ISP 15NS LO-P PLCC28 1 U2
N062006536 IC PLD XC9536 15nS PLCC-44 3 U1, 19, 21
N063002302 IC OPT COUPLER PC410 1 U11
N063010402 IC FLOPPY DRIVE GM82C765B PLCC44 1 U9
Part No. Description Qty. Reference Designation

Kurzweil K2600 Series Specifications

General

Polyphony	48 voices
Multitimbral	16 parts
MIDI	In, Out, Thru
Type	Workstation
Synthesis Method	VAST (Variable Architecture Synthesis Technology)
Keyboard	61, 76, or 88 keys
Sequencer	16-track sequencer
Display	LCD
Sampling	Yes, with optional sampling option
Storage	Floppy disk
Audio Outputs	Stereo outputs
Audio Inputs	Stereo inputs
