6-20
Parts Lists
K2600 Series Keyboard Models
Slider Board, N012104345
N061013851 IC LOGIC 74HC164 SOP14 2 U5, 6
N061013902 IC LOGIC 74HC273A SOP20 1 U8
N061014003 IC LOGIC MC74HC541DW SOP-20 1 U2
N062005704 IC GAL 16V8A-15QJ SMT PLCC20 1 U3
N062100101 IC SRAM 32KX8 70nS SOP28 GM76C256A70 1 U7
N064001302 IC LINEAR +5V 100MA 5% 78L05ACM SOP-8 1 VR1
N064001602 IC LINEAR OPAMP TL072 SOP8-160 1 U9
N262001602 IC M37451M8-283FP 1 U1
N062200406 IC EP-ROM OTP AT27C 256R-12PC 1
Part No. Description Qty. Reference Designation
N035026101 LARGE BUTTON W/LED PC-88 3 BUTTON
N035026128 LARGE BUTTON W/LED (1) K2600 1 BUTTON
N035026129 LARGE BUTTON W/LED (2) K2600 1 BUTTON
N035026130 LARGE BUTTON W/LED (3) K2600 1 BUTTON
N035026131 LARGE BUTTON W/LED (4) K2600 1 BUTTON
N035026132 LARGE BUTTON W/LED (5) K2600 1 BUTTON
N035026133 LARGE BUTTON W/LED (6) K2600 1 BUTTON
N035026134 LARGE BUTTON W/LED (7) K2600 1 BUTTON
N035026135 LARGE BUTTON W/LED (8) K2600 1 BUTTON
N035026321 SLIDER KNOB PC-88 9 KNOB
N035026411 SLIDER BEZEL PC-88 9 BEZEL
N039000701 SLIDE VOLUME FELT 0.3TX12X70 9 FELT
N041030020 HEADER SIP .098" SP 4P R/A (22-02-7045) 1 J304
N041030021 HEADER SIP .098" SP 6P R/A (22-02-7065) 1 J301
N041030030 HEADER DUAL ROW 1" SP 16P R/A 1 J303
N041034107 CONN RIGHT .098 SP 7P (22-05-7075) 1 J302
N043010201 SWITCH TACK 6mmX3.5mm 160GF ALPS SKHLAC 11 S1-11
N045010610 LED MINI RED/GREEN DIFUSSED T1 DKL-30RGM 11 D1-11
N051101502 SLIDER VOLUME SINGLE 10KB-LIN 45mm 8 R1-8
N051101610 SLIDER VOLUME 10KAX2 45MM GOLDSTAR ALPS 1 R9
N052001204 CAP CER MONO Z5U .1UF 50V 20% .3AX 1 C1
N061008110 IC 74HC4051 DUAL MUX DIP16 1 U1
Part No. Description Qty. Reference Designation
