Kurzweil K2600 Series User Manual

6-6
Parts Lists
K2600R/K2600RS
K2600R/K2600RS
Audio Board, N012305605
Part No. Description Qty. Reference Designation
N032055802 BRACKET SUPPORT AUDIO PCB K2600R 1
N041025305 HEADER .156" SP 5P (09-65-2058) 1 J602
N041031216 HEADER .1" SP DUAL ROW 16P (057-016-153) 1 J601
N041034003 HEADER .098" SP 3P (22-03-5035) 1 J615
N041034005 HEADER .098" SP 5P (22-03-5055) 1 J611
N041034006 HEADER .098" SP 6P (22-03-5065) 1 J612
N041034501 PHONE JACK STEREO 1/4" RA49C-14B 10 J603-610, 613, 614
N051080401 RES TF 1.0KΩ 5% 1/10W 0805 1 R215
N051080410 RES TF 100Ω 5% 1/10W 0805 2 R235, 236
N051080411 RES TF 10KΩ 5% 1/10W 0805 1 R205
N051080412 RES TF 4.12KΩ 1% 1/10W 0805 8 R65-68, 133-136
N051080447 RES TF 470Ω 5% 1/10W 0805 2 R211, 214
N051080464 RES TF 4.64KΩ 1% 1/10W 0805 16 R25-28, 45-48, 93-96, 113-116
N051080576 RES TF 57.6KΩ 1% 1/10W 0805 8 R21-24, 89-92
N051080604 RES TF 6.04KΩ 1% 1/10W 0805 8 R5-8, 73-76
N051080610 RES TF 10.0KΩ 1% 1/10W 0805 26 R193-204, 206, 207, 209, 213, 216-219, 222, 223, 231-234
N051080617 RES TF 1.78KΩ 1% 1/10W 0805 8 R140-142, 161-163, 181, 182
N051080628 RES TF 6.98KΩ 1% 1/10W 0805 16 R49, 51, 53, 55, 57-60, 117, 119, 121, 123, 125-128
N051080630 RES TF 30.1KΩ 1% 1/10W 0805 20 R146-151, 167-172, 185-188, 221, 224, 227, 228
N051080632 RES TF 8.45KΩ 1% 1/10W 0805 16 R9, 11, 13, 15, 17-20, 77, 79, 81, 83, 85-88
N051080633 RES TF 15.0KΩ 1% 1/10W 0805 16 R29, 31, 33, 35, 37-40, 97, 99, 101, 103, 105-108
N051080635 RES TF 3.57KΩ 1% 1/10W 0805 24 R1-4, 69-72, 137-139, 143-145, 158-160, 164-166, 179, 180, 183, 184
N051080636 RES TF 22.6KΩ 1% 1/10W 0805 8 R61-64, 129-132
N051080639 RES TF 31.6KΩ 1% 1/10W 0805 8 R10, 12, 14, 16, 78, 80, 82, 84
N051080646 RES TF 53.6KΩ 1% 1/10W 0805 8 R50, 52, 54, 56, 118, 120, 122, 124
N051080649 RES TF 4.99KΩ 1% 1/10W 0805 4 R208, 212, 237, 238
N051080675 RES TF 76.8KΩ 1% 1/10W 0805 8 R30, 32, 34, 36, 98, 100, 102, 104
N051080686 RES TF 226KΩ 1% 1/10W 0805 8 R41-44, 109-112
N051102103 RELAY 5V DPDT (G6H-2-DC5) 11 RY1-11
N051125201 RES TF 200Ω 1% 1/4W 1210 20 R152-157, 173-178, 189-192, 225, 226, 229, 230
N051204010 RES TF 10Ω 5% 1/2W 2010 1 R220
N051204047 RES TF 47Ω 5% 1/2W 2010 2 R239, 240
N052001711 CAP ELECT 100UF 25V 20% RAD 4 C5, 6, 17, 18
N052002405 CAP ELECT 22UF 16V 20% .08 SP 1 C129
N052004203 CAP ELECT 47UF 35V 20% SHL 16 C20, 22, 24, 26, 82, 84, 86, 88, 190, 191-197
N052005105 CAP ELECT 100UF 10V RAD 1 C188
N052007503 CAP CER X7R 0.1UF 50V 10% 1206 75 C1, 3, 7-10, 14, 15, 27, 28, 69, 71, 73, 74, 78, 79, 130-187, 189
N052080012 CAP CER NPO 68PF 50V 2% 0805 8 C45-48, 105-108
N052080015 CAP CER NPO 150PF 50V 2% 0805 8 C57-60, 117-120
N052080022 CAP CER NPO 220PF 50V 5% 0805 8 C11-13, 16, 75-77, 80
N052080023 CAP CER NPO 180PF 50V 2% 0805 8 C33-36, 93-96

Kurzweil K2600 Series Specifications

General

Polyphony	48 voices
Multitimbral	16 parts
MIDI	In, Out, Thru
Type	Workstation
Synthesis Method	VAST (Variable Architecture Synthesis Technology)
Keyboard	61, 76, or 88 keys
Sequencer	16-track sequencer
Display	LCD
Sampling	Yes, with optional sampling option
Storage	Floppy disk
Audio Outputs	Stereo outputs
Audio Inputs	Stereo inputs
