Kurzweil K2600 Series - Floppy Disk Drive Assembly, N012104666; Backlight Board, N012104311

Parts Lists
K2600 Series Keyboard Models
6-15
Floppy Disk Drive Assembly, N012104666
Backlight Board, N012104311
N035028011 LCD LOCATING SUPPORT BEZEL K2500 1
N042005401 JUMPER WIRE 13MMX4MM 67
N043010201 SWITCH TACK 6mmX3.5mm 160GF ALPS SKHLAC 41 S1, 2, 4-10, 12-16, 19-24, 26-32, 35-48
N044010501 ENCODER 36STEP 2BIT 1 SP1
N045010111 LED T1 RED HI EFF DIFFUSED LTL-4221 8 D3-6, 9-12
N045010610 LED MINI RED/GREEN DIFUSSED T1 DKL-30RGM 2 D7, 13
N051000906 RES 10KX9 10P 1 RP1
N051005010 RES CF 1Ω 5% 1/8W 1 R3
N051100102 RES CF 15Ω 5% 1/8W 8 R1, 2, 4, 9
N051100138 RES CF 2.2KΩ 5% 1/8W 1 R10
N052001204 CAP CER MONO Z5U .1UF 50V 20% .3AX 5 C2-5, 7
N053000801 DIODE 1N4148 DO-35 12 D101-112
N054000801 TRANSISTOR PN2222 TO-92 9 Q1-8, 16
N054001201 TRANSISTOR PNP KTA1271 (KSA643CY) TO-92 6 Q9-12, 14, 15
N061013601 IC LOGIC 74HC138 DIP16 1 U2
N061014001 IC LOGIC 74HC541 DIP20 1 U1
N061020501 IC LOGIC 74HC373 DIP20 1 U3
N252003102 CAP ELECT ECE-BOJU471 470UF 6.3V VERT AX 2 C1, 6
Part No. Description Qty. Reference Designation
N015000602 FLOPPY DISK DRIVE 3.5" OF SAMSUNG 1
N025313307 MACHINE SCREW FH M3X6 BLK 2
N025323306 MACHINE SCREW BH 3X6 BLK 4
N027112100 FLAT WASHER 3.3X6.5X0.5 2
N032037211 BRACKET FDD MOUNTING K2500 1
N035028214 FDD BEZEL K2600 1
Part No. Description Qty. Reference Designation
N025223408 TAPPING SCREW-2 BH M3X8 BLK (SMALL) 4
N032025761 BRACKET MOUNTING PCB LCD INVRT K2600/X 1
N032035411 POWER INVERTOR PCB SHIELD 1
N041032104 HEADER 0.2" SP 4P MOLEX (10-32-1041) 1 J2
N041034102 HEADER .098" SP 2P R/A (22-05-7025) 1 J1
N042005405 JUMPER WIRE 5MM 1 U2 (1 & 3)
N055000010 INVERTER (CXA-L10L) 1 U1
Part No. Description Qty. Reference Designation
