Kurzweil K2600 Series User Manual

Parts Lists
K2600 Series Keyboard Models
6-19
Keyboard Scanner Board, N012305415
Part No. Description Qty. Reference Designation
N041010302 JUMPER .1" SP 2POS JUMPER 1 @J703 PINS 1& 2
N041021128 IC SOCKET .6W 28P 1 @U4
N041030003 HEADER .1" SP 3P (22-03-2031) 2 J703
N041030511 HEADER .098" SP 7P (22-03-5075) 1 J702
N041031210 CONN .1" SP DUAL ROW 14P (057-014-153) 1 J714
N041031220 HEADER .1" SP DUAL ROW 20P (057-020-153) 1 J705
N041031240 CONN .1" SP DUAL ROW 40P (057-040-153) 1 J704
N041034005 HEADER .098" SP 5P (22-03-5055) 1 J709
N041034010 HEADER .098" SP 10P (22-03-5105) 1 J701
N041034411 CONN STEREO 1/8" W/SWITCH UNITOP 1 J708
N041034501 PHONE JACK STEREO 1/4” RA49C-14B 6 J706, 707, 710-713
N051102302 POT R/A 10K 12RV03 (JUNG POONG) 1 R89
N052002401 CAP ELECT 100UF 16V 20% .138 SP 2 C15, 17
N052002405 CAP ELECT 22UF 16V 20% .08 SP 1 C9
N052004201 CAP ELECT 10UF 35V 20% .08SP 1 C22
N052005105 CAP ELECT 100UF 10V RADIAL 2 C10, 18
N051064010 RES TF 100Ω 5% 1/16W 0603 28 R26-41, 43-54
N051064110 RES TF 10Ω 5% 1/16W 0603 33 R11-19, 21, 22, 55-72, 75, 79, 80, 87
N051100392 RES MF 1MΩ 1% 1/8W 1206 1 R76
N051100393 RES TF 1.10MΩ 1% 1/8W 1206 1 R82
N051101279 RES TF 4.32KΩ 1% 1/8W 1206 1 R90
N051101700 RES CF 0Ω 5% 1/8W 1206 3 R4, 23, 42
N051101704 RES CF 10Ω 5% 1/8W 1206 1 R2
N051101713 RES CF 100Ω 5% 1/8W 1206 4 R24, 77, 91, 101
N051101730 RES CF 1.0KΩ 5% 1/8W 1206 10 R3, 6-10, 92-95
N051101745 RES CF 4.7KΩ 5% 1/8W 1206 2 R73, 103
N051101757 RES CF 10KΩ 5% 1/8W 1206 5 R96-99, 104
N051101760 RES CF 20KΩ 5% 1/8W 1206 1 R102
N051101790 RES CF 1.0MΩ 5% 1/8W 1206 2 R1, 5
N051101794 RES CF 1.5MΩ 5% 1/8W 1206 1 R85
N051103020 RES CF 2.21KΩ 1% 1/8W 1206 1 R100
N051103059 RES MF 20KΩ 1% 1/8W 1206 1 R81
N051103061 RES TF 34.8KΩ 1% 1/8W 1206 1 R88
N051103070 RES MF 100KΩ 1% 1/8W 1206 2 R83, 86
N051103073 RES CF 165KΩ 1% 1/8W 1206 1 R84
N051103097 RES CF 49.9KΩ 1% 1/8W 1206 1 R78
N052007033 CAP CER 33PF 50V 5% NPO 1206 2 C1, 3
N052007402 CAP CER 1000PF X7R 1206 8 C11, 13, 16, 20, 23-26
N052007503 CAP CER X7R 0.1UF 50V 10% 1206 20 C2, 4-8, 12, 14, 19, 21, 27-36
N053000802 DIODE SWITCH 1N4148 SMT DL-35 15 D1-6, 10-18
N053010502 DIODE SHOTTKY 1A 20V 5817(SS12) SMT 3 D7-9
N054000802 TRANSISTOR MMBT2222L SOT-23 1 Q3
N054002906 TRANSISTOR MMBT2907L SOT-23 3 Q1, 2, 4
N059010050 XTL 12.0000MHz +/-50PPM FND PAR 18PF SMT 1 Y1

Kurzweil K2600 Series Specifications

General

Polyphony	48 voices
Multitimbral	16 parts
MIDI	In, Out, Thru
Type	Workstation
Synthesis Method	VAST (Variable Architecture Synthesis Technology)
Keyboard	61, 76, or 88 keys
Sequencer	16-track sequencer
Display	LCD
Sampling	Yes, with optional sampling option
Storage	Floppy disk
Audio Outputs	Stereo outputs
Audio Inputs	Stereo inputs
