4-14
K2600/K2600X Disassembly/Assembly
Top Enclosure
5. Place the enclosure support wall in position.
6. Install the enclosure support wall screws. You should see thread marks in the extrusion to
verify proper positioning of the enclosure support wall screws.
Note: If you are servicing a K2600, there are seven screws securing the enclosure support
wall. If you are servicing a K2600X, there are eight screws.
7. Connect the flat ribbon cable that connects the Control Panel Board to the Keyboard
Scanner Board. Be sure to install the cable locking clip.
