10. Audio Mix Engine
10.9.3 TConn64
"Connect -> TConn64"
The TConn64 is a 64-into-1 stereo connect, ideal for larger monitoring signal selectors. Each TConn64 may
be assigned up to 64 stereo audio inputs which are switched to a single stereo output by 64 trigger inputs.
Switch between parameters using the Global and In 1-16, In 17-32, etc. menu tabs at the top of the parameter
area.
In 1-64 Parameters
Trigger In N
Assigns an input control signal which connects:
· Audio In N.1 to Audio Out 1
· Audio In N.2 to Audio Out 2
Audio In N.1
Assigns the left audio input source.
Audio In N.2
Assigns the right audio input source.
