LAWO POWER CORE - MADI IO

Power Core User ManualVersion: 6.6.0/372/539
9. Audio IO
MADI IO
Input Parameters
Input N
Use this field to name the input (as described earlier).
Type / Stereo
Use the Type and Stereo fields to set the format of the input (as described earlier).
Dig Offset Gain
Here you can enter a fixed digital offset gain for the input.
Matrix Enable
This option enables matrix control of the input (as described earlier).
Transparent
Select this checkbox to set the input to be “transparent”. The option should be enabled if you are
using the input to route a Dolby E signal.
Output Parameters
Output N
Use this field to name the output (as described earlier).
Type / Stereo
Use the Type and Stereo fields to set the format of the output (as described earlier).
Offset Gain
Here you can enter a fixed digital offset gain for the output.
Matrix Enable
This option enables matrix control of the output (as described earlier).
If the option is enabled, you cannot use the Default Audio function.
Transparent
Select this checkbox to set the output to be “transparent”. The option should be enabled if you are
using the output to route a Dolby E signal.
Default Audio
Double-click in the Default Audio box to assign a default audio source for the output (as described
earlier).
