LAWO POWER CORE - Static Network Route

Power Core User Manual Version: 6.6.0/3 391/539
20. Configuring Custom Logical Behaviour
20.25 Static Network Route
"Logic -> Static Network Route"
This element can be used to configure a static network route for the streaming ports (ra0 & ra1) or control ports
(dwc0 & dwc1). It is supported by Power Core systems only.
General Parameters
Static Network Route
Enter a reference name for the element.
Disabled
Use this checkbox to disable the route.
Device Group
Select the network interfaces which will be affected. You can choose either the streaming
ports (ra0 & ra1) or control ports (dwc0 & dwc1).
Route Type
Select the type of route: either Host or Subnet.
Host Name / IP Address
Enter the host name and IP address.
Gateway Name / IP
Address
Enter the gateway name and IP address.
