Power Core User Manual Version: 6.6.0/3 87/539
9. Audio IO
9.3.10 Global RAVENNA Settings
The following branches of the 'Tree Definition' define the global RAVENNA settings.
Start by selecting "System -> Definition" in 'Tree Definition' and the Ravenna tab. Scroll down to access the
parameter sets.
Stream Announcement
"System -> Definition -> Parameter = Stream Announcement"
These parameters define the mDNS and SAP channels used for stream announcement:
·
mDNS channels use the multicast Domain Name System defined in IETF RFC 6762.
·
SAP channels use the Session Announcement Protocol defined in IETC RFC 2974.
For each channel, enter the multicast IP Address, Port Number and TTL value (in seconds). Use the Enable
checkbox to enable or disable the channel.
For convenience, temporary changes to the channel settings can be made from the Power Core Web UI (via
the RAVENNA -> Global tab).
