6. Installation
Power Core is designed to be mounted in a 19-inch rack. Please install supporting slide bars to hold the weight
of the unit, and use the locking devices provided. For recessed rack-mounting, use standard, third-party, 1RU
recessed rack adapters such as the ones shown above. When fitting the rack adapters and slide bars, you
must make sure that there is sufficient airflow around the device for cooling.
Connectors are located at the front and rear of the unit. Therefore, when using 19-inch racks with doors please
leave enough room for the cables.
If you have IO cards to install, then these should be fitted BEFORE installing the unit into the rack.
