Power Core User Manual Version: 6.6.0/3 413/539
21. Networking Power Core
Enter a Reference name for the element/device
Enter the number of the Ember+ Consumer you wish to use (as defined under "System ->
Definition -> Parameter = Local Consumers").
Initial Replication Direction
This option determines the initial replication direction following a restart. The default direction
(Consumer -> Provider) will read the values from the A__stage device.
GPI
These tabs configure the 8 GP inputs:
Reference name for the input. This can be any name - e.g. Red Light.
GPIs 1 to 8 will correspond to GPOs 1 to 8 within the mirroring device, providing that both
sides have an identical Reference Name.
