Safety 2-25
After the door switch is reset you must put the feed kitchen into operation.
2.4.3.5 Safety door
Figure 17. Safety door
KEY: 1. Lock - 2. Door - 3. Access control switch
Risk of accident caused by a malfunctioning safety gate.
Serious injury or death.
Do not tamper with the safety gate.
The safety door (2) has a lock (1) that needs to be opened. When opened the access control switch is
activated.
During normal operation when the lock is tilted unauthorized, the feed grabber, bridge crane and safety
fence immediately stop operation.
Be aware that the MFR will not stop operation.
To reset the access control switch, close and lock the safety door and put the feed kitchen into operation.
