Figure 218. Installing the riser 3 assembly
• 4LP riser 3/4 assembly
1. Install the riser cage tray.
Figure 219. Installing the riser cage tray
a. Align the riser cage tray with the screws that secure the riser cage tray.
b.
Install the screws to fix the riser cage tray to the chassis.
2. Install the riser 3 assembly and riser 4 assembly into the riser cage.
244
ThinkSystem SR665 V3 User Guide
