Lenovo ThinkSystem SR665 V3 - Page 329

Figure 303. SAS/SATA cable routing
Figure 304. NVMe cable routing
From To From To
1 Backplane 1: SAS 1 CFF adapter
• C0
• C1
1 Backplane 1: NVMe 0-1
1 Onboard: PCIe 5
2 CFF adapter: MB (CFF
INPUT)
2 Onboard: PCIe 9
2 Backplane 1: NVMe 2-3
2 Onboard: PCIe 7
3 CFF adapter: PWR 3 Onboard: CFF RAID/
HBA PWR
3 Backplane 1: NVMe 4-5
3 Onboard: PCIe 6
4 Backplane 1: NVMe 6-7
4 Onboard: PCIe 8
Chapter 6. Internal cable routing 319
