Parameter Name / value range / [default seng] Info
0x2631:010
(P400.10)
Funcon list: Jog foward (CW)
(Funcon list: Jog foward)
•
Seng can only be changed if the inverter is inhibi-
ted.
•
For further possible sengs, see parameter
0x2631:001 (P400.01). ^ 532
Assignment of a trigger for the "Jog foward (CW)" funcon.
Trigger = TRUE: Let motor rotate forward with preset 5.
Trigger = FALSE: Stop motor.
CAUTION!
The jog operaon has a higher priority than the "Run" funcon, all other
start commands and the keypad key .
•
If jog operaon is acve, the motor cannot be stopped with the previ-
ously menoned funcons!
•
However, jog operaon can be interrupted by the "Quick stop" func-
on.
Notes:
•
The preset value 5 can be set in 0x2911:005 (P450.05).
•
The stop method can be selected in 0x2838:003 (P203.03).
•
If "Jog foward (CW)" and "Jog reverse (CCW)" are acvated at the
same me, the motor is stopped using the stop method and jog oper-
aon must be triggered again.
•
Jog operaon cannot be started automacally. The "Start at power-
up" opon in 0x2838:002 (P203.02) does not apply to jog operaon.
0 Not connected
0x2631:011
(P400.11)
Funcon list: Jog reverse (CCW)
(Funcon list: Jog reverse)
•
Seng can only be changed if the inverter is inhibi-
ted.
•
For further possible sengs, see parameter
0x2631:001 (P400.01). ^ 532
Assignment of a trigger for the "Jog reverse (CCW)" funcon.
Trigger = TRUE: Let motor rotate backward with preset 6.
Trigger = FALSE: Stop motor.
CAUTION!
The jog operaon has a higher priority than the "Run" funcon, all other
start commands and the keypad key .
•
If jog operaon is acve, the motor cannot be stopped with the previ-
ously menoned funcons!
•
However, jog operaon can be interrupted by the "Quick stop" func-
on.
Notes:
•
The preset value 6 can be set in 0x2911:006 (P450.06).
•
The stop method can be selected in 0x2838:003 (P203.03).
•
If "Jog foward (CW)" and "Jog reverse (CCW)" are acvated at the
same me, the motor is stopped using the stop method and jog oper-
aon must be triggered again.
•
Jog operaon cannot be started automacally. The "Start at power-
up" opon in 0x2838:002 (P203.02) does not apply to jog operaon.
0 Not connected
0x2631:012
(P400.12)
Funcon list: Acvate keypad control
(Funcon list: Keypad control)
•
For further possible sengs, see parameter
0x2631:001 (P400.01). ^ 532
Assignment of a trigger for the "Acvate keypad control" funcon.
Trigger = TRUE: acvate keypad as control source.
Trigger = FALSE: no acon / deacvate keypad as control source again.
0 Not connected
0x2631:017
(P400.17)
Funcon list: Acvate network setpoint
(Funcon list: Setp: Network)
•
From version 02.01
•
For further possible sengs, see parameter
0x2631:001 (P400.01). ^ 532
Assignment of a trigger for the "Acvate network setpoint" funcon.
Trigger = TRUE: the network is used as setpoint source (if the trigger
assigned has the highest setpoint priority).
Trigger = FALSE: no acon / deacvate funcon again.
0 Not connected
116 Network setpoint acve (from version 02.00) TRUE if a change-over to network setpoint is requested via bit 6 of the
AC drive control word0x400B:001 (P592.01). Otherwise FALSE.
Notes:
•
Set this selecon if the network setpoint is to be acvated via bit 6 of
the AC drive control word.
•
The AC drive control word can be used with any communicaon pro-
tocol.
4AC Drive Prole ^ 248
Conguring the network
General network sengs
